214 x 214mm Reprap MK3 Aluminum Board Aluminum Heatbed Heat Bed

More Views

214 x 214mm Reprap MK3 Aluminum Board Aluminum Heatbed Heat Bed
$5.42

Availability: In stock

EXW Price

This is Reprap MK3 Aluminum Board, dimension 214x214x3mm 12V or 24V option
Description

Details


214 x 214mm Reprap MK3 Aluminum Board Aluminum Heatbed Heat Bed


Description:

Voltage: 12V / 24V
Power: 120W
Resistance: 12V voltage, resistance 1.2 ohms; 24V voltage, resistance 4.8 Ohm
Size: 214mm * 214mm * 3mm
Process: aluminum ple
1 layer 35μm (1oz base) copper
Resistance between 1.4 and 1.6 ohm for the 12V
Resistance between 5.0 and 5.4 ohm for the 24V
100 degree Celsius possible for both 12V and 24V
With 15V on the 12V terminals will maintain approx. 115 degree Celsius without regulion
Running 24V on the 12V terminals will heup the hebed to 100 degree in only 2 minutes (Your printer controller will regule the power to the hebed in order to get your temperure.)
180 degree Celsius max. temperure
Resistance 1.2ohm in 12v when 2 and 3 connect with 1, resistance 4.8ohm in 24v when 2 conenct with 3

Package Includes:

1xMK3 Hebed

Note: Please be reminded th due to lighting effects and monitor's brightness/contrast settings etc, the color tone of the website's photo and the actual item could be slightly different.
